About CCMC
Corporate Introduction
Hangzhou Semiconductor Wafer Co.,Ltd.

Hangzhou Semiconductor Wafer Co., Ltd. was established in 2017, and located in Qiantang District,Hangzhou.

It mainly engaged in manufacturing of high quality semiconductor wafers, with the annual production capacity of 2.4 million pieces 12-inch, 4.8 million pieces 8-inch and 4.8 million pieces 6-inch.

We are committed to be one of the main suppliers of semiconductor wafers in the world.

Construction Site：
Construction Site：

Dajiangdong Industrial Cluster Area, Qiantang District


Construction Time：
Construction Time：

It was officially established on September 28, 2017, and the foundation stone was laid on December 18, 2017


Construction Scale：
Construction Scale：

Covers an area of more than 133,400 square meters, factory building area of about 150,000 square meters


Construction Goals：
Construction Goals：

It will build a company with an annual production capacity of 12.6 million silicon wafers (including 2.4 million silicon wafers of 300mm, 4.8 million silicon wafers of 200mm and 4.8 million silicon wafers of 150mm), become one of the main suppliers of semiconductor silicon wafers in the world, and break the long-term monopoly of foreign companies in the semiconductor silicon wafer market.Realize the semiconductor silicon material industry truly "Made in China".


Technological Level：
Technological Level：

The 200mm production line is the semiconductor silicon wafer production line with advanced scale and mature technology in China.At present, 300mm production line is a semiconductor silicon wafer production line with core technology in China, which can truly achieve mass production.


Company Group:
Company Group:

More than 50% of the employees have bachelor degree or above, and 70% have college degree or above. The key management and technical personnel have many years of semiconductor experience.

At the same time, the company has brought in overseas semiconductor management and technical teams, bringing together technical talents from Japan, South Korea, Chinese mainland and Taiwan, and the company have trained a team of local and international level, sustainable development of large-scale semiconductor silicon technology and management personnel.


Supporting Advantages
Opportune Time
Opportune Time
It is a strategic opportunity period for the development of China's integrated circuit industry. Driven by the trade friction between China and the United States, it is extremely urgent to establish a complete supply chain of semiconductor core materials.

The supply of domestic large-size silicon wafers, especially the 12-inch semiconductor wafers is basically controlled by foreign enterprises, and the market is highly monopolized. The completion and commissioning of the Zhongxin Wafer project will change the current situation that domestic large-size semiconductor wafers are dependent on foreign countries, effectively filling the supply of large domestic semiconductor wafer industry short board.


Geographic Advantage
Geographic Advantage
In the industrial planning of Qiantang area, the intelligent manufacturing industrial cluster-the Semiconductor industry cluster is the top priority of the five leading industrial clusters.

With the completion and production of the US $1 billion Zhongxin wafer project, the area has formed a complete industrial chain from semiconductor R & D and design, packaging and testing to production and sales to promote the Semiconductor industry of our country.


Popular Support
Popular Support
Ferrotec (China) group has 28 years of manufacturing experience.70% of the products are related to the semiconductor business, involving semiconductor materials, equipment and related supporting services.

By integrating Ferrotec group's semiconductor silicon wafer industry, Zhongxin factory will become Ferrotec's flagship semiconductor silicon wafer company, and form to Hangzhou factory (200mm, 300mm silicon wafer processing), Shanghai factory (200mm, 150mm silicon wafer processing) and Yinchuan factory (single wafer long wafer) to the integrated Ferrotec silicon wafer industry pattern in three places, its has an annual output of 12.6 million silicon wafers (including 2.4 million pieces of 300mm, 5.4 million pieces of 200mm and 4.8 million pieces of 150mm) production capacity, the company has advanced production capacity in China, filling the gap of large-scale and mass production of large diameter silicon wafers in China, breaking the long-term monopoly of foreign companies on the semiconductor silicon wafer market, and realizing the real "Made in China" in the semiconductor silicon material industry, and it will also open a new chapter of China's semiconductor large-diameter silicon wafer business!
